10G SR SFP+ Optical Module 850nm Multi-mode MMF Dual LC 300m DDM Pluggable:
$33.07









This Small Form Factor Pluggable (SFP) transceiver is SFP+ module for duplex optical data communications such as 10GBASE-SR and 10GBASE-SW. It is with the SFP+ 20-pin connector to allow hot plug capability. Digital diagnostic functions are available via an I2C. This module is designed for multi-mode fiber and operates at a nominal wavelength of 850nm.


The transmitter section uses a Vertical Cavity Surface Emitted Laser (VCSEL) and is a Class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated GaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.



Features


Up to 11.1Gbps Data Links


850nm VCSEL transmitter and GaAs PIN PD receiver


Maximum link length of 300m via OM3 multimode Fiber (MMF)


Compliant with IEEE 802.3ae 10GBASE-SR/SW


Hot pluggable 20pin connector


Operating temperature range:0°C to +70°C



Application


Inter Rack Connection


High-speed Servers


10GBASE-SW at 9.953Gbps/10GBASE-SR at 10.3125Gbps


High-performance Computing Clusters


SAN, Routers, Hubs, Load Balancer


Compliance


Compliant with SFF-8472









Special reminder
Our production process is continuously improved, so there may be slight differences in appearance and color among products produced in different batches. These differences do not affect the functionality of the product or your experience in using it. Thank you very much for your understanding.
