NEW - Cisco Catalyst C9300X-48HX-M Meraki 48x Multi-Gig Switch - UNCLAIMED:
$8899.99

BRAND NEW - UNCLAIMEDPort & Performance Hardware

  • Downlink Ports: 48× 10G Multigigabit (mGig) RJ-45 ports supporting 100M / 1G / 2.5G / 5G / 10G speeds.

  • Power over Ethernet (PoE): Cisco UPOE+ (IEEE 802.3bt) up to 90W per port.

  • Uplink Options: 1× Modular Uplink Expansion Slot (supports optional 1G / 10G / 25G / 40G / 100G uplink modules).

  • Switching Capacity: Up to 2,000 Gbps (2 Tbps).

  • Forwarding Rate: ~1,488 Mpps.

  • Stacking Bandwidth: Up to 1 Tbps physical stacking bandwidth via Cisco StackWise-1T.

  • Stacking Capacity: Supports up to 8 switches in a single stack.

System Architecture & Hardware

  • Processor / ASIC: UADP 2.0sec ASIC + x86 CPU.

  • RAM / Flash: 16 GB DRAM / 16 GB Flash Memory.

  • Storage Extension: Supports optional USB 3.0 SSD (up to 240 GB) for app hosting / containers.

  • Management: Native Cisco Meraki Cloud Management (dashboard zero-touch provisioning, analytics, remote troubleshooting).

Power & Energy

  • Installed Power Supply: Includes 1× 1100W AC Power Supply Module (PWR-C1-1100WAC-P).

  • Power Redundancy: Dual hot-swappable power supply slots (1 installed, 1 open slot).

  • Default PoE Budget: 590 W with single 1100W PSU (expandable with secondary power supply).

  • StackPower: Supported (shares power across stack members for redundancy).

Dimensions & Weight

  • Form Factor: 1U Rack-Mountable

  • Dimensions (H × W × D): 1.73 in × 17.5 in × 22.0 in (4.4 cm × 44.5 cm × 55.9 cm)

  • Weight: Approx. 14.6 lbs (6.62 kg)
